General Description
S-500 CF is a chlorine-free, non-toxic, non-irritating and non-corrosive water soluble oil. Following are some of its benefits: Amine-free, Phosphate-free and Nitrite-free; Bio-stable formulation for extended life and minimized waste; Ideal for continuous use recycling systems and central systems; Multi-purpose formulation eliminates need for multiple coolants thus reduces inventories; Approved by Bombardier Aerospace, Lord Aerospace and Lockheed Martin; Approved for use in the Semi-Conductor Industry. Advanced Synthetic Extreme Pressure Additives. Outstanding performance on aluminum machining, including small drills and small taps. Compatible with all common machine tool components, including paint and seals. Excellent rejection of foreign contamination, including tramp oils.
Application
Primary applications of S-500 CF would include CNC Turning, Tapping and Threading, Sawing and Cut-off, High Speed Machining, Conventional Contract Shop Applications, CNC Milling and Drilling, Reaming and Boring, Light Stamping, High Pressure Machining. Secondary applications are Broaching, Shaping and Slotting, Drawing, Heavy Stamping, Grinding which includes Centerless, Creepfeed, Surface, ID/OD and Rotary, Gear Cutting and Finishing, Forming, Fine Blanking.
Materials
Primary: Aluminum Alloys, High Temperature Alloys, Nickel Alloys, Stainless Steel, Steel (all forms), Powdered Metals, Tool Steel and High Speed Steel, Titanium. Secondary: Brass, Bronze and Copper Alloys, Ductile Iron and Cast Iron, Ceramics, Glass, Precious Metals, Plastics and Composites, Refractory Metals.
Maintenance
S-500 CF is a bio-stable coolant, designed to control the growth of bacteria. Regular maintenance is required for maximum performance. Concentration should be monitored regularly with a calibrated refractometer. S-500 CF gives a direct read on the refractometer (e.g. 5=5%). Tramp oils should be removed from the coolant surface regularly to prevent unwanted bacterial growth. Keep the coolant system free of cleaners, solvents and other contaminants.
Cleaning
Easy to clean off in aqueous and non-aqueous cleaning systems.
Instructions
Pre-mixing Procedures: Always premix coolant before adding to the machine sump. Never add straight water or straight concentrate directly to the machine's sump. For best results a Hangsterfer’s recommended proportioning device should be used. If mixing by hand, always add concentrate to water, and then agitate. It is important to remember that as water evaporates from the coolant, the concentration will increase. To maintain the recommended concentration in the machine, make-up coolant should be pre-mixed at half the % concentration as the initial fill. To maintain 6% in the machine, first charge the machine at 6%, then add make-up at 3% to keep the machine full. This will keep the machine at 6%. Never add just straight water to reduce the concentration, always add a light pre-mixed coolant.
SDS: Download Hangsterfer's S-500 CF Safety Data Sheet (SDS)
